Features:

• 2-Channel Micro Class-D Amplifier
• Power Output:
• 150W RMS x 2 @ 4Ω
• 250W RMS x 2 @ 2Ω
• 500W RMS x 1 @ 4Ω Bridged
• Ultra-compact, high density aluminum alloy chassis provides superior thermal stability
• Four layer, glass epoxy circuit board for enhanced performance and reliability
• Full Range Class D amplifier technology
• Balanced differential inputs for superior noise rejection
• Input sensitivity from 200mV to 10V accepts line (RCA) and Speaker level input
• Selectable auto-turn-on modes: Signal Sensing (VOX), 12V Remote (REM) and DC offset (DC)
• Fully variable, 12dB per octave, electronic crossover
• Variable 18dB per octave sub-sonic filter
• Adjustable Bass EQ (45Hz: 0dB to +12dB)
• Wired Remote Level Control included
• Illuminated logo
• THD: 0.5%
• S/N Ratio (A weighted @ 1W): -85dB
• Low Input Level: 200mV - 10.0V
• Bandwidth(-3dB): 10Hz - 350Hz
• Variable High-Pass: 40Hz - 400Hz
• Variable Low-Pass: 40Hz - 400Hz
• Fuse Ratings - ATC: 25A
• Dimensions: 7.89"L x 4.0"W x 1.46"H
