Features:

• XPE Series 4-Channel Class A/B Car Amplifier
• RMS Power Rating (14.4V <1% THD+N):
  • 4 ohms: 50 watts x 4 chan.
  • 2 ohms: 75 watts x 4 chan.
  • Bridged, 4 ohms: 150 watts x 2 chan.
• Dynamic power output: 800 watts @ 4 ohms
• Pulse Width Modulated MOSFET power supply
• Bi-color LED status indicators
• Selectable bass boost (0, 6, 12 dB at 45 Hz)
• Soft Start Turn-on
• 4/3/2 channel operation
• Speaker-level inputs with signal sensing for automatic turn-on
• 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
• Heavy duty aluminum alloy heatsink for extreme heat dissipation
• Silver-plated RCA level inputs
• Silver-plated screw terminals
• Input sensitivity:
  • Low level: 125mV-5V
  • High level: 250mV-10V
• Variable high-pass filter (50-500 Hz, 24 dB/octave)
• Variable low-pass filter (50-500 Hz, 24 dB/octave)
• CEA-2006 compliant amplifier
• Frequency response: 20-20,000 Hz
• Dimensions: 8-15/16 Inch L x 14-1/8 Inch W x 2-1/16 Inch H

Specifications:

Power Specifications - Full Range Channels:

• RMS Power @ 4 ohms: 50 watts x 4 channels
• RMS Power @ 2 ohms: 75 watts x 4 channels
• RMS Power @ 1 ohm: Not Stable
• Bridged RMS Power: 150 watts x 2 channels

Amplifier Specifications:

• Amplifier Class: AB
• Number of Channels: 4
• Total Peak Power Output: 800 watts
• Total RMS Power Output: 300 watts
• Maximum Input Gauge Size: 8 AWG
• Minimum Impedance Unbridged: 2 ohms
• Minimum Impedance Bridged: 4 ohms
• THD at Rated RMS Power: <1%
• Speaker Level Inputs: Yes
• Preamp Outputs: No
• Built-in Crossover: Low-Pass (LP), High-Pass (HP), Full (AP)
• High-Pass Crossover Frequency: 50 - 500 Hz
• Low-Pass Crossover Frequency: 50 - 500 Hz
• Signal-to-Noise Ratio: 70 dB
• Bass Boost: 0dB, 6dB, 12dB
• Bass/Gain Remote: No
• Fan Cooled: No
• Fuse Rating: 25A x 2
